Order number: 04.16.22.100

Automatic push-button shower fitting SABA Q1.2-PZ.1 FIL

Order number: 04.16.22.100

Automatic push-button shower fitting SABA Q1.2-PZ.1 FIL

The SABA Q1.2-PZ.1 FIL automatic push-button shower fitting is a wall-mounted shower fitting with an upper shower head, equipped with a thermostatic mixer and push-button control of the water flow via a piezoelectric button. The pre-wall concept allows for easy installation without the need for structural interventions in the wall, which makes it an ideal solution for new and renovated shower areas.

The device is equipped with an electronic START–STOP system, which starts the water flow after pressing a piezoelectric button. The water flow stops automatically after 23 seconds from start or by pressing the button again.

The operating parameters of the device can be adjusted via the remote control, which allows flexible adaptation of the shower mode to specific operational requirements.

The faucet is also equipped with an integrated DEAVX Plus Base antibacterial filter, which ensures physical water filtration and effectively reduces the presence of Legionella pneumophila bacteria directly at the outlet. This solution provides an additional level of user protection, especially in facilities with high hygiene requirements and irregular use of shower facilities.

The device has a preset automatic hygienic flush with a period of every 72 hours and also offers the possibility of setting central and manual thermal disinfection. The fitting is equipped with a bypass of the hot water branch for the needs of central and individual triggering of thermal flushing. Thanks to these functions, it meets high hygienic requirements for operation and is an ideal solution for healthcare facilities, sports facilities and all highly frequented shower areas.

Add to cart

Add to cart
Added to cart

Key Parameters

  • Control typePiezoelectric, (START-STOP system)
  • Shower panel dimensions220 x 1250 x 78 mm
  • Water connection2 × G 3/8"
  • Power supply6 V DC lithium battery or external power supply 230 V AC / 6 V DC depending on the variant
  • Water flow7 l/min (depending on the shower head used)
  • Working pressure0.5 – 10 bar
  • Recommended pressure1 – 5 bar
  • Maximum cold water temperature25 °C
  • Maximum hot water temperature70°C
  • Operational statisticsArchiving of operating data, cycle counter, hygiene protocols
  • Parameter settingRemote Control DO-5.1

Special Features

  • Automatic hygienic flush

  • External input for hygienic flushing

  • Thermal Disinfection

  • STOP function

  • Hygiene protocol
